Tamiya RC buggy Hotshot II Blockhead Motors 1/10 KIT

Product detailed description

An RC model kit of one of Tamiya's first 4WD buggies, released in 1987. The decals were designed by Jún Watanabe's "BLOCKHEAD MOTORS" brand, which deals in decals, clothing and modification of off-road Tamiya buggies from the 1980s, with also participates in designing fashion, music and skateboard projects.

Parameters:
Scale: 1/10
Length: 390mm
Width: 235mm
Height: 150mm
Body: Pre-painted polycarbonate
Electric motor: 540er

Features:
The new protective cage is placed higher, which ensures an elevated position of the driver and gives the model greater realism.
Improved upper frame
The posts and wheels are plated with a matte finish.
New stickers designed by Jun Watanabe "BLOCKHEAD MOTORS".
Registration numbers, light bases, side plates, window nets and antenna are part of the package.
The 4-wheel two-link suspension uses one front transverse and two rear CVA II oil shock absorbers.
Package contents: Building kit of the Buggy model, 540er electric motor, ESC controller, pre-painted body, instructions

Need to purchase: RC set, steering servo, 7.2 - 7.4V battery, charger, transmitter batteries

Run-in of the new electric motor
New model with engine, needs to be run in first. Before starting to use the DC electric motor, it is definitely recommended to run it. Some manufacturers require it as a condition for recognizing a possible engine claim.The purpose of the run-in is to seat the rotating parts well, smooth the friction surfaces of the contacts, and grind the carbons into the correct shape. The current enters the motor on the commutator surfaces using the so-called carbons, which may not have a perfectly adapted shape from production. If the new motor is loaded to the maximum without a previous run-in, the commutator surface or the carbons may be damaged due to large "sparking". The run-in will allow the carbon to settle on the commutator, so they will wear out less and last a longer period of operation.

Electric motor run-in procedure:
-If you have a new RC model car or boat in which the engine is already mounted, proceed as follows. Place the model on the mat so that the wheels rotate above the surface. Let the engine run at the lowest possible speed for 20-30 minutes. You can then drive the model for 20-30 minutes at a lower speed and gradually increase the speed. Drive the model at full power only after the running-in phase has passed.

-If you have a new engine that has not yet been installed in the model, you can do the run-in in the traditional, proven way immersed in water. Connect the motor to the ESC controller and lower it by the cables vertically down into a container of clean water. Start the engine at low speed and let it run for 10-15 minutes. Then you can gradually increase the speed for a few minutes up to the maximum. Finally, pull the motor out of the water and let it run for a while to blow the water out of the motor. You can install a run-in engine in the model and you can immediately drive at full power. You don't have to worry about the engine submerged in water. It will work normally and the water will cool it during the run-in. In addition, it washes out carbon particles during grinding (the water visibly darkens).

Protection against overheating of the electric motor:
Since the stator is made of permanent magnets, it is good to know that the magnets gradually lose their "power". However, temperature also has a big impact. Each electric motor heats up during operation and can reach a temperature of 60°C (therefore, after driving, the motor must not be touched with bare hands!). If the engine is not cooled, or cooled insufficiently, or if it is driven for a long time at maximum speed, it may overheat and thus weaken the magnets. Even after cooling down, the engine will no longer reach its previous performance. Of course, other parts of the engine can also be damaged by high heat. It is therefore advisable to change the load mode, or to drive with two smaller accumulators with a break for replacement and cooling, rather than with one large-capacity one for a long time at full power.

Electric motor replacement, tuning:
The new motor should be of the same type (size), have the same number of turns and the same supply voltage value as the original one. That way, you will be sure that the model will retain its original driving characteristics.
If you are planning a tuning motor, first of all, check whether the original ESC controller in the model will be able to work with the tuning motor, in order not to burn the ESC controller, or to prevent the ESC-motor system from working. When tuning a motor, it is usually necessary to replace the pinion as well.

WARNING! This RC car is not a toy, but a sophisticated, functional model that behaves very much like a real car. Due to its realistic parameters, if it is not correctly assembled and operated correctly, it can cause you injury, or injure the viewer, or damage property. The model is intended for driving in a large room or outside on a dry surface. Driving in water, snow, puddles and mud without proper waterproofing can damage the model's electronics. Driving on public roads and other places (e.g. parking lots) with car traffic is prohibited.Do not drive in thick grass, you will overheat or burn the engine!
